Tätning
37º JIC Kona SAE J516/ ISO 12151-5
Material
Stål
| Artikelnr | Benämning | Beteckning | Anslutning | Slang dim. | A-mått | NV |
| 12-57640404 | Pressnippel 5764-04-04 | JIC 716" 45° - 1/4" sl. | 7/16"-20 | 1/4 | 31mm | 14mm |
| 12-57640504 | Pressnippel 5764-05-04 | JIC 1/2" 45° - 1/4" sl. | 1/2"-20 | 1/4 | 32mm | 17mm |
| 12-57640604 | Pressnippel 5764-06-04 | JIC 9/16" 45° - 1/4" sl. | 9/16"-18 | 1/4 | 33mm | 19mm |
| 12-57640606 | Pressnippel 5764-06-06 | JIC 9/16" 45° - 3/8" sl. | 9/16"-18 | 3/8 | 35,5mm | 19mm |
| 12-57640806 | Pressnippel 5764-08-06 | JIC 3/4" 45° - 3/8" sl. | 3/4"-16 | 3/8 | 37,5mm | 22mm |
| 12-57640808 | Pressnippel 5764-08-08 | JIC 3/4" 45° - 1/2" sl. | 3/4"-16 | 1/2 | 41mm | 22mm |
| 12-57641008 | Pressnippel 5764-10-08 | JIC 7/8" 45° - 1/2" sl. | 7/8"-14 | 1/2 | 43mm | 27mm |
| 12-57641010 | Pressnippel 5764-10-10 | JIC 7/8" 45° - 5/8" sl. | 7/8"-14 | 5/8 | 47mm | 27mm |
| 12-57641208 | Pressnippel 5764-12-08 | JIC 1 1/16" 45° - 1/2 | 1 1/16"-12 | 1/2 | 45,5mm | 32mm |
| 12-57641210 | Pressnippel 5764-12-10 | JIC 1 1/16" 45° - 5/8" sl. | 1 1/16"-12 | 5/8 | 50mm | 32mm |
| 12-57641212 | Pressnippel 5764-12-12 | JIC 1 1/16" 45° - 3/4" sl. | 1 1/16"-12 | 3/4 | 59mm | 32mm |
| 12-57641412 | Pressnippel 5764-14-12 | JIC 1 3/16" 45° - 3/4" sl. | 1 3/16"-12 | 3/4 | 59mm | 36mm |
| 12-57641612 | Pressnippel 5764-16-12 | JIC 1 5/16" 45° - 3/4" sl. | 1 5/16"-12 | 3/4 | 61mm | 41mm |
| 12-57641616 | Pressnippel 5764-16-16 | JIC 1 5/16" 45° - 1" sl. | 1 5/16"-12 | 1 | 72mm | 41mm |
| 12-57642016 | Pressnippel 5764-20-16 | JIC 1 5/8" 45° - 1" sl. | 1 5/8"-12 | 1 | 76mm | 50mm |
| 12-57642020 | Pressnippel 5764-20-20 | JIC 1 5/8" 45° - 1 1/4" sl. | 1 5/8"-12 | 1 1/4 | 95mm | 50mm |
| 12-57642424 | Pressnippel 5764-24-24 | JIC 1 7/8" 45° - 1 1/2" sl. | 1 7/8"-12 | 1 1/2 | 113mm | 60mm |
| 12-57643232 | Pressnippel 5764-32-32 | JIC 2 1/2" 45° - 2" sl. | 2 1/2"-12 | 2 | 150mm | 75mm |
